| APPLICATION PROCESSOR |
NXP i.MX8QuadXPlus
- 4x Cortex — A35 cores at 1.2 GHz
- 1x Cortex — M4F at 266 MHz core for real-time processing
- 1x Tensilica® Hi-Fi 4 DSP
|
| MEMORY |
Up to 16 GB eMMC, up to 2 GB LPDDR4 (32-bit) |
| GRAPHICS |
Multi-stream-capable HD video engine with H.265 (4Kp30), H.264 (1080p60), VP6/VP8 (1080p60), MPEG-2 (1080p60), MPEG4 (1080p),
RealVideo (1080p) decode and H.264 (1080p30) encode; 3D video playback in HD in high-performance families; superior 3D graphics performance with up to 4 shaders |
| DISPLAYS |
2x LVDS/MIPI with backlight control and I2C touch interface |
| CAMERA |
1x 8-bit Parallel Camera Interface, 1x MIPI Camera 2x lanes |
| AUDIO |
2x Line-In, 1 x Line-Out, 1x Mic-In, 1x Headset on 3.5mm audio jack |
| UART/CONSOLE |
4-pin header (console), 2x UARTs on expansion connector |
| SECURITY |
Digi TrustFence®, TRNG, TrustZone, Ciphers, Security Control, Secure RTC, Secure JTAG, eFuses (OTP) |
| ETHERNET |
2x Gigabit Ethernet 10/100/1000M with AVB on RJ-45, with 2 LEDs for link/speed/activity |
| WI-FI |
2 x 2 MIMO 802.11a/b/g/n/ac: 2.412 - 2.484 GHz, 4.900 - 5.850 GHz
Security: WEP, WPA-PSK/WPA2-Personal, WPA/WPA2 Enterprise, 802.11i, Soft Access Point Mode (up to 10 clients) |
| BLUETOOTH |
Bluetooth® 5 |
| ANTENNA CONNECTORS |
2 x U.FL on module |
| DIGI XBEE RF |
Standard Digi XBee® socket |
| USB |
2x USB 2.0 Host, 1x USB 3.0 on Type-C connector |
| PCI EXPRESS MINI CARD* |
Full-size card support, with on-board Micro SIM slot support – dedicated 3A power supply |
| OTHER CONNECTIVITY |
2x CAN, 1x SPI, 1x I2C, 1x expansion connector |
| EXTERNAL STORAGE |
MicroSD |
| BOOT CONFIGURATION |
On module eMMC, on SBC microSD, serial downloader and boot from fuses |
| DEBUG |
1x JTAG for i.MX 8X (Tag-Connect), 1x SWD for MCA (Tag-Connect and header) |
| BUTTONS |
1x power button (power on, power off, sleep, wake-up), 1x reset button |
| LEDS |
2x user LEDs (1x yellow, 1x green), 1x power LED (3.3 V) |
| POWER INPUTS |
5 V at 3.2 A (typical, depending on use-case), 1x coin cell 2-pin header |
| POWER SUPPLY CONNECTOR |
Main power supply via 2mm locking barrel connector, or dedicated power connector (2-pin header) |
| POWER OUTPUTS |
3.3 V Out (2-pin header), 5 V Out (2-pin header) |
| OPERATING TEMPERATURE |
−40 °C to 85 °C (−40 °F to 185 °F) |
| STORAGE TEMPERATURE |
−50 °C to 125 °C (−58 °F to 257 °F) |
| RELATIVE HUMIDITY |
Relative humidity 5% to 90% (non-condensing) |
| RADIO APPROVALS (PENDING) |
US, Canada, EU, Japan, Australia/New Zealand |
| EMISSIONS/ IMMUNITY/ SAFETY (PENDING) |
FCC Part 15 Class B, EN 55024, EN 55032 Class B, ICES-003 Class B, VCCI Class II,
FCC Part 15 Subpart C Section 15.247 and 15.407, IC (Industry Canada), EN 300 328, EN 301 893, EN 300 440, EN 301 489-1/-17, EN 55024, EN 301 489-3 |
| DESIGN VERIFICATION (PENDING) |
Temperature: IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-78;
Vibration/Shock: IEC 60068-2-6, IEC 60068-2-64, IEC 60068-2-27, HALT |
| MECHANICAL DIMENSIONS |
100 mm x 72 mm (3.9 in x 2.8 in) |
