Digi IX40 5G Edge Computing Industrial IoT Solution

Now with Digi 360

5G edge computing industrial IoT cellular router solution, purpose-built for Industry 4.0


Digi IX40 with Digi 360 Digi IX40 industrial cellular router Front (Digi IX40) Back (Digi IX40) Digi IX40 — SIM animation Left side (Digi IX40) Right side (Digi IX40) Digi Remote Manager multiscreen - light mode Watch the IX40 introduction video
  • Global 5G and LTE support and certification on major carriers
  • Integrated industrial edge computing capabilities for hosting containerized applications and custom solutions
  • Support for CBRS and global private 5G networking deployments
  • Ethernet, SFP, serial, I/O and Modbus bridging
  • Extremely resilient cellular connection through Digi’s patented SureLink®, VRRP+ protocol and dual SIM slots
  • GNSS receiver supporting GPS, GLONASS, BeiDou and Galileo
  • License-free enterprise software: VPN, firewall, logging and authentication
  • Rugged enclosure with options for DIN rail or shelf mounting
  • Includes the Digi 360 solution with warranty, customer care and Digi Remote Manager® cloud management, enabling easy setup, mass configuration and management
  • Access to Digi value-added services, including Digi Containers for powerful, cost-efficient applications and Digi WAN Bonding for WAN aggregation and immediate failover
How to Buy Support

Digi IX40 is a 5G edge computing industrial IoT router solution to empower rapid processing, analysis, and integration of industrial asset data on 5G public and private cellular networks — easy to deploy and centrally managed via Digi Remote Manager® (Digi RM), which is included in your Digi 360 solution.

Purpose-built for Industry 4.0, Digi IX40 supports the 5G connectivity and edge intelligence needed to enable numerous use cases ranging from predictive maintenance and asset monitoring to machine learning and advanced robotics. It seamlessly connects multiple machines, whether wired or wireless, in the most demanding environments, optimizing integration of cloud-delivered operational technology (OT) services with information technology (IT) to streamline complex operations and scale IT infrastructure.

With its all-in-one design, strong computing power and integrated memory, Digi IX40 offers substantial capabilities for real-time data processing, edge computing and advanced precision while reducing complexity and total cost of ownership. Digi Containers facilitate potent and cost-effective applications, providing additional flexibility and scalability for Industry 4.0, energy, smart cities and other uses.

The Digi IX40 solution offers FirstNet Capable™ models designed to meet the demands of critical applications where reliability is essential for industrial use cases and emergency response. Additional use cases for Digi IX40 include manufacturing process automation, precision monitoring and control, industrial automation, utilities and traffic management.

Gain critical insights and manage your network with Digi RM — the cloud-based command center for your deployment. Digi RM also provides secure terminal access for out-of-band management of edge devices via serial port and command-line interface.

5G
Digi TrustFence
FirstNet Ready
OnGo Alliance
Download datasheetDownload datasheet User manualsUser manuals & guides Related productsRelated products Add to compareAdd to compare

Now With Digi 360

Digi 360 offers comprehensive cellular solutions, including purpose-built devices, software and services, to help customers optimize their IoT investments and maximize ROI. These complete solutions are designed to simplify IoT complexity, and ease the challenges enterprises face in configuring, deploying and managing their IoT initiatives.

Icon depicting stats from remote management Management
Icon depicting a router Device
Icon showing a headset with 24/7 label Customer Care
Icon depicting a badge with checkmark Warranty
Learn More

Digi WAN Bonding Logo

Introducing Digi WAN Bonding

Digi WAN Bonding combines multiple connections into a seamless and resilient connectivity solution that ensures optimal performance and maximum uptime anywhere around the world.

Learn More

Play Watch the
Video

Introducing Digi Containers

Managing the increasing complexity of IoT applications just got easier. Meet Digi Containers, a value-added service available as an add-on to a Digi Remote Manager® license. The Digi Containers service puts you in control, and helps you simplify your operations.

Compare Industrial Routers

Compare Industrial Routers

Take Command.

Your Network. Your Way.

PlayWatch the Video
Take Command. Your Network. Your Way.

Manage Your Network Your Way

Remote device management: network-wide updates, data insights and control. Digi Remote Manager delivers centralized visibility and automates processes at your command, with actionable 24/7 remote monitoring.

Automated Network Monitoring
Automated Network Monitoring

To keep tabs on dozens, hundreds or thousands of active connected devices requires network monitoring software. Human eyes can't keep up. With Digi RM remote monitoring tools, you're in command. As your IoT device management platform, Digi RM watches your network for disruptions and intrusions, and lets you know when you need to take action. Set alerts for important conditions. Get reports on network performance. Check on any device, anywhere, anytime.

Configuration Management
Configuration Management

Digi Remote Manager has what other IoT device management platforms don't: the ability to configure all of your devices at once, make individual configuration changes, and still manage those specialized configurations in groups. Create group and individual configurations. Deploy rapidly and accurately. Let Digi RM monitor device security.

Firmware Updates
Firmware Updates

Today's IoT devices are smarter, more feature rich, and have more tasks to perform at the edge. And they are not static. You may need to update firmware to enhance functionality, download custom scripts, keep your devices in compliance with corporate security policies, or deploy patches for threats to IoT security. Digi Remote Manager puts the network management tools in your hands to deploy firmware updates or send files to your devices in minutes, even if you have a network of many thousands of devices. Manage your dynamic network with a few clicks. Keep your devices secure.

Edge Computing
Detection and Troubleshooting

Digi RM is always on, even during your network manager’s off hours. As your network monitoring solution, Digi RM lets you know when issues arise, sending alerts and delivering reports so your team can rest easy. At any time, they can gain the insights needed on the health of the entire network or individual devices and remotely troubleshoot, test and reboot devices as needed. Put network monitoring tools to work for you, so you can work smarter.

Related Products

Digi IX20 Industrial 4G LTE Router Digi IX20 Industrial 4G LTE Router Digi IX30 Industrial Cellular Router Digi IX30 Industrial Cellular Router Digi IX10 Industrial Cellular Router Digi IX10 Industrial Cellular Router Digi Remote Manager Digi Remote Manager Digi Containers Digi Containers Digi WAN Bonding Digi WAN Bonding
SPECIFICATIONS Digi IX40 with Digi 360*
WIRELESS INTERFACES
CELLULAR / WWAN**
IX40-05: 5G NSA, 5G SA***, 4G LTE-ADVANCED PRO CAT 19 5G NR bands: n1, n2, n3, n5, n7, n8, n12, n13, n14 FirstNet®, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n71, n75, n76, n77, n78, n79;
4G LTE-Advanced Pro bands: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14 FirstNet®, B17, B20, B25, B26, B28, B29, B30, B32, B38, B40, B41, B42, B43, B46, B48, B66, B71;
3G bands: B1, B2, B3, B4, B5, B6, B8, B19
IX40-04: 4G LTE-ADVANCED PRO CAT 12, 3G HSPA+ 4G LTE-Advanced Pro bands: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B38, B39, B40, B41, B42, B43, B48, B66, B71;
3G bands: B1, B2, B4, B5, B6, B8, B9, B19
CONNECTORS (2) or (4) 50 Ω SMA;  center pin: female
SIM SLOTS (2) Nano-SIM (4FF) holders
SIM SECURITY SIM slot cover plate included
GNSS
TECHNOLOGY GPS Gen 9 with band L1 LNA for passive antenna use
ANTENNA Upper L-band: GPS L1; Glonass G1; Beidou B1; Galileo E1
IX40-04: supports passive GNSS antennas rated at 1.5 to 3 dBi only
IX40-05: supports passive GNSS antennas rated at 1.5 to 3 dBi or active antennas with 7.5 to 26 dB gain
PROTOCOL NMEA 4.11 and TAIP
CONNECTOR (1) 50 Ω SMA;  center pin: female
WIRED INTERFACES
ETHERNET
PORTS / CONNECTOR (4) RJ-45; 10/100/1000 Mbps Base-T (auto-sensing); IEEE 802.3; configurable as WAN or LAN
I/O
PORTS / CONNECTOR (2) Digital input/outputs; (2) analog inputs (0 - 10 V; 4 - 20 mA; 12-bit resolution)
SFP
PORTS / CONNECTOR (2) 1 Gb capable SFP sockets
SERIAL
PORTS / CONNECTOR (1) RS-232/422/485; DB-9 male (DTE)
SOFTWARE & MANAGEMENT*
REMOTE MANAGEMENT Digi Remote Manager (cloud based); SNMP v1/v2c/v3 (user installed/managed), SMS
LOCAL MANAGEMENT Web UI (HTTPS); CLI (SSH, serial)
MANAGEMENT TOOLS SFTP, SCP; protocol analyzer with PCAP for Wireshark; event logging with Syslog
PROCESSOR
APPLICATION PROCESSOR 1.6 GHz quad-core i.MX 8M Plus ARM® Cortex®-A53 processor
MEMORY
RAM / FLASH 1 GB / 8 GB
PHYSICAL
DIMENSIONS (L X W X H) 234 mm x 154 mm x 41 mm (9.21 in x 6.06 in x 1.61 in)
WEIGHT 1.14 kg (2.51 lb)
STATUS LEDS Power, WWAN, Ethernet (link, activity)
ENCLOSURE/RATING Glass-filled polyphenylene sulphide / IP30 −40 °C to 85 °C (−40 °F to 185 °F)
POWER REQUIREMENTS
POWER INPUT 12 to 30 VDC, reverse polarity protection
POWER CONNECTOR Screw down removable terminal block
POWER CONSUMPTION 4.5 W (light traffic), 8 W (peak data), 3.5 W (idle traffic)
ENVIRONMENTAL
OPERATING TEMPERATURE −40 °C to 75 °C (−40 °F to 167 °F); reduced cellular performance may occur above 70 °C (158 °F)
STORAGE TEMPERATURE −45 °C to 85 °C (−49 °F to 185 °F)
RELATIVE HUMIDITY 0% to 95% (non-condensing) at 25 °C (77 °F)
APPROVALS**
CELLULAR PTCRB, AT&T, FirstNet Capable™, T-Mobile, Verizon;
SAFETY / SECURITY IEC 62368-1, CB scheme, FIPS 140-2
EMISSIONS / IMMUNITY FCC Part 15 Subpart B, ISED, CE, RED, UKCA
WARRANTY****
PRODUCT WARRANTY 1-year
*Includes the Digi 360 solution for Digi IX40 (1-year) with Digi Remote Manager, warranty and customer care.
**Visit product certifications for latest approvals and updates.
***Contact your network operator regarding 5G SA support on their network. Digi IX40-05 supports up to 2xCC (2x 5G SA Carrier Components).
****Product warranty can be extended with Digi 360 extensions or renewals.

ENTERPRISE SOFTWARE DESCRIPTION
PROTOCOL SUPPORT HTTPS, TLS, SCP (client and server), SFTP, SNMP (v3), SSH, Telnet and CLI for web management; remote management via Digi Remote Manager®; protocol analyzer, ability to capture PCAP for use with Wireshark; DynDNS, Dynamic DNS client compatible with No-IP/DynDNS; Captive portal, Intelliflow; Nagios, DNS server, NTP server, Multicast, mDNS, IPerf
SECURITY / VPN IP filtering, stateful inspection firewall with scripting, address and port translation; VPN: IPSec with IKEv1, IKEv2, NAT Traversal; SSLv3, FIPS 197, Open VPN client and server; L2TP; VPN tunnels; cryptology: SHA-1, MD5, RSA; encryption: DES, 3DES and AES up to 256-bit (CBC mode for IPsec); authentication: RADIUS, TACACS+, SCEP for X.509; certificates; content filtering (via 3rd party); MAC address filtering; VLAN support
ROUTING IP pass-through; NAT, NAPT with IP port forwarding; Ethernet bridging; GRE; multicast routing; routing protocols: PPP, PPPoE, RIP (v1, v2) OSPF, BGP, iGMP routing (multicast); IP failover: VRRP, VRRP+TM; automatic failover/failback to second GSM network/standby APN; Digi SureLink®
EMISSIONS / IMMUNITY DHCP; Dynamic DNS client compatible with No-IP/DynDNS; QoS via TOS/DSCP; Modbus UDP/TCP to serial; Modbus bridging for connecting diverse field assets

*For a comprehensive list of operating system features, please visit digi.com/solutions/by-technology/dal-operating-system/features.
